Summit apparel
Protective outer-layer development for high-altitude summit clothing.
WS10Q123
Extreme protection
A 23 g/m² nanofiber membrane for summit apparel development, with a focus on protective outer layers for exposed, high-altitude environments.
Membrane basis weight
23 g/m²Membrane performance
Product brochure (English) ↗Values are reproduced from the product brochure and refer to the listed membrane grades. Test methods are shown separately; results across methods are not directly interchangeable. Finished laminate performance depends on fabrics, adhesive, processing and care. Confirm the current specification and test report for your project.
| Property / test method | WS10Q123 |
|---|---|
| Basis weightg/m²Nominal value | 23 |
| Hydrostatic pressure · GB/T 4744-2013mmH₂O | 11,000 |
| Hydrostatic pressure · JIS L1092-2025 BmmH₂O | 15,000 |
| Air permeability · GB/T 5453-1997mm/s | >0.8 |
| Elongation · GB/T 3923.2-2013% | >30 |
| Thickness · GB/T 3820-1997µm | 40 |
| Moisture vapor transmission · JIS L1099-2021 B1g/m²/24h | >15,000 |
Finished fabric possibilities
High-altitude expedition wear
Summit apparel fabric development with a 23 g/m² nanofiber membrane, for high-altitude outerwear and protective garment systems.
DEVELOPMENT TARGETS · BEFORE WASHING
- Waterproofness
- ~20,000mmH₂O
Target evaluation methodJIS L 1092:2025 B
- Water-vapour transmission
- ~15,000g/m²/24h
Target evaluation methodJIS L 1099:2021 B-1
- Air permeability
- ~0.8mm/s
Target evaluation methodGB/T 5453-1997
Indicative development targets before washing, not measured results. Final laminate performance is validated with the selected fabrics, lamination process and test method.
Request a sampleMore ways to use it
Application examples are development directions. Validate the complete laminate against the requirements of your intended use.
